| Brand | One Source Light |
| Model | J-T2-S40-3565 |
| Product Type | LED Center Lens Recessed Troffer |
| Size | 2×2 FT |
| Wattage (Field Selectable) | 15W / 20W / 25W / 30W / 40W |
| Color Temperature (CCT) | 3500K / 4000K / 5000K / 5700K / 6500K (5 Options – Field Selectable) |
| Maximum Wattage | 40W |
| Maximum Lumens | 5,200 LM (40W @ 130 lm/w) |
| Lumen Output at Each Setting | 15W: 1,950 LM | 20W: 2,600 LM | 25W: 3,250 LM | 30W: 3,900 LM | 40W: 5,200 LM |
| Efficacy (LM/W) | 130 LM/W |
| CRI (Color Rendering Index) | ≥ 80 |
| Input Voltage | 120-277V AC |
| Total Harmonic Distortion (THD) | ≤ 20% |
| Dimmable | Yes (0-10V DC Standard) |
| Sensor Base | YES – Pre-embedded in Profile Frame |
| Optical System | Precision Formed Center Lens (Reduces Glare) |
| Housing Material | One-Piece Ribbed Unitized Housing |
| Housing Features | Interlocking Corners | All Sides & Corners Turned In & Hemmed | Prevents Damage |
| Driver | Universal Voltage (120V-277V) | Fixed on Back to Prevent Mis-Handling |
| Length | 23.74 inches (603mm) |
| Width | 23.74 inches (603mm) |
| Height | 2.12 inches (53.9mm) |
| Installation | Recessed Ceiling Mount |
| Optional Sensor Types | PIR Motion Sensor (3.5mm Audio Jack) | Bluetooth PIR Motion Sensor (3.5mm Audio Jack) |
| Optional Accessories | PIR Motion Sensor | Bluetooth Motion Sensor | Emergency Backup (8W, 90 min) |
| Energy Savings | Over 50% Energy Savings vs Traditional Fluorescent Fixtures |
| Operating Features | Low Heat Production | Reduces Maintenance & Operation Cost |
| Certifications | ETL Listed | DLC 5.1 Premium | FCC | RoHS |
| Lifetime | 50,000 Hours Rated |
| Warranty | 5-Year Limited |
| Application Areas | Commercial Offices, Retail Spaces, Educational Facilities, Healthcare, Hospitality, General Task Lighting |
