Description

• ELECTICAL
  • Dual 120V/277 voltage standard. Optional dual 120V/230V available.
  • Unique bi-color LED indicator light alerts occupant on battery condition (Green-normal, Red-check battery).
  • 3.6V long life, maintenance-free, rechargeable Ni-Cd battery.
  • 3.0W of remote capacity standard
  • Internal solid-state transfer switch automatically connects the internal battery to LED board and connected LED lamp heads for minimum 90-minute emergency illumination.
  • Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
• MOUNTING
  • EZ-snap thermoplastic mounting canopy included –provides top or end mount.

  • Universal K/O pattern on back plate for wall mount.
• HOUSING

  Injection-molded, engineering grade, 5VA flame retardant, high-impact, thermoplastic in white or black finish.
• OPTIONS

  • SPV: UL Listed for special voltage option.

  • SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes. Universal 120-277 voltage.
• WARRANTY/LISTINGS

  • Five year warranty on all electronics and housing. Battery prorated for five years.

  • UL Listed for damp locations (0°C  – 40°C).

  • Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.

  • Certified to CEC under Title 20 Regulations.
