Description

• Sealed die-casting profile for outdoor applications.
• Dark bronze finish as standard
• Casting thermally conducts LED heat to optimize performance and long life.
• The design with zero uplight meets the requirements of dark sky.
• Switchable color temperature 3000K/4000K/5000K.
• Adjustable lumen output with four lumen settings 100%, 80%, 60%, 40%.
• Scalable Lumen Packages from 2,750 to 15,000 Lumens.
• Zero uplight distributions using individual acrylic.
• High performance UV stabilized optical grade polymer refractor lenses to achieve desired distribution optimized to get maximum spacing, target lumens and a superior lighting uniformity.
• Universal 120-277 VAC input voltage.
• 0-10V dimming standard for a dimming range of 100% to 10%.
• Both drivers have a power factor >90%,THD <20%.
• Operating Temperature Range: -40°C to 40°C (-40°F – + 104°F).
• Optional Occupancy sensor, Microwave sensor, Multifunction Sensor or daylight sensor or photo control.
• Optional Bluetooth sensor or Bluetooth controller.
• Silvair Luminaire Level Lighting Control (LLLC) optional
• Sharkward Luminaire Level Lighting Control (LLLC) optional.
• Haisen Luminaire Level Lighting Control (LLLC) optional.
• Also compatible with 􏚴rd party smart network control system.
• High End Trim
• Optional Emergency Battery
• Estimated 50,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations.
• Five-year limited warranty
• UL cUL wet location listed.
• DLC Qualified
