Descripton

• Universal 120-277V, 50/60 Hz input.
• Charge/Power “ON” LED indicator light and push-to-test
  switch for mandated code compliance testing.
• Long-life, maintenance free, rechargeable NiCad battery.
• Output short/overcurrent protection: Electronic limiting, with normal operation resuming upon removal of fault.
• 90-minute minimum emergency operating time over full temperature range.
• Output classification: Class 2 Compliant.
• Surge protection: Per C62.41 (TVS).
• Input overcurrent protection: Fusible link.
• 24 hour maximum battery recharge time.
• Works with or without an AC Driver to convert new or existing LED fixtures into unobtrusive emergency lighting.
• Provides constant power output to the load during emergency mode operation.
• Can be operated as NORMALLY-ON, NORMALLY-OFF or SWITCHED LOAD.
• Ideal for use with canopy lights, garage lights and any outdoor fixture that needs emergency lighting.
• Low-profile, unobtrusive design.
• LED illuminated and remote mounted test switch.
• Sealed and gasketed, powder-coated, die-cast aluminum housing.
• Provided with 2-ft flex conduit and conduit hub.
• UL Listed for factory or field installation.
• Suitable for wet locations (-20°C – 50°C).
• Five year warranty on all electronics and housing.
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State codes.
• Certified to CEC under Title 20 regulations.
