NSF DLC Premium LED UFO High Bay

Products

LED NSF Highbay
NSF certified for food processing and food-safe environments — ideal for poultry processing, food & beverage processing, commercial kitchens and manufacturing facilities
Streamlined smooth housing prevents accumulation of food debris, dust and other substances — premier choice for harsh ambient lighting
IP66 & IP69K rated — withstands high-pressure washdowns
Corrosion resistant; no harmful substances or chemicals
Wattage : 150W
Lumen output : 21,900 lm @ 5000K
Standard efficacy : 150 lm/W
CCT : 5000K
CRI : Ra80 (general efficacy)
Sealed optic with 115° beam angle
Lens : PC (polycarbonate)
Integral heat sink optimizes thermal transfer and maximizes LED performance
Finish : White (standard for NSF certification)
Input Voltage : AC100-277V, 50/60Hz
0-10V Dimmable driver (dims from 100% down to off)
Operating Temperature : -40°C to 45°C — cULus Listed for wet locations
Mounting : O Hook (standard); G Hook and 3/4″ NPS Pendant Mount optional; Safety Hanging Kit standard
Optional Microwave Sensor (built-in, installed in the middle of lens; Max Installation Height: 8M / 26FT)
Optional Accessories : Remote Controller, Polycarbonate Refractor, Drop Lens, 30W Emergency Battery Backup
NSF Certified, cULus Listed (wet location), DLC Premium Qualified
5-year limited warranty

MPN (Part No.)	X-HBDU150W-50KSV-DNCB
Lighting Technology	LED
Fixture Type	LED NSF Highbay — Diamond Series (UFO)
CRI	Ra80 (General Efficacy)
Beam Angle	115° (Sealed Optic)
Color Temperature	5000K
Wattage	150W
LPW	150 lm/W (Ra80 Standard)
Lumens	21,900 lm @ 5000K (Ra80)
Voltage	AC100-277V
Frequency	50/60Hz
Current @ 120V	1.25 A
Current @ 208V	0.72 A
Current @ 240V	0.63 A
Current @ 277V	0.54 A
Current @ 347V
Current @ 480V
Dimming	0-10V Dimmable (100% to Off)
Driver	Non-Isolated (C)
Ratings and Certifications	NSF Certified, cULus Listed (Wet Location), DLC Premium
IP Rating	IP66 & IP69K
Finish	White (Standard for NSF Certification)
Lens	Glass or PC (Polycarbonate) — both NSF certified
Housing	Corrosion-Resistant, Smooth Streamlined Design with Integral Heat Sink
Mounting	O Hook (Standard); G Hook & 3/4″ NPS Pendant Optional; Safety Hanging Kit standard
Optional Sensor	Microwave Motion Sensor (Max Installation Height: 8M / 26 FT, installed in middle of lens)
Optional Accessories	Remote Controller, Polycarbonate Refractor, Drop Lens, 30W Emergency Battery Backup
Operating Temp	-40°C to 45°C
Diameter	17.08 in. (434 mm)
Body Height	5.7 in. (145 mm)
Overall Height (O Hook)	7.56 in. (192 mm)
Overall Height (G Hook)	8.4 in. (214 mm)
Warranty	5-Year Limited
